Signal path
Requirements
- Line-level source
- Downstream preamplifier or amplifier
- Suitable stereo interconnects
Specifications
| Input/output | Estimate: 1 stereo RCA pair each |
|---|---|
| Modes | Estimate: Relay true bypass plus 2 validated active modes |
| Gain | Estimate: Near unity with calibrated level matching; exact values published |
| Tube | Estimate: One common dual triode or final validated complement |
| Power | Estimate: 120 VAC or approved external supply; final design controls |
| Enclosure target | Estimate: Approximately 9 W x 7 D x 4 H in body |
| Standard lead time | Estimate: 8 weeks |
| Production estimate | Made to order; estimated 8 weeks, confirmed with the accepted order. |
| Opening price | $879 base; options priced only when available in the configurator. |
| Black finishes | Satin black or polished piano black; piano black adds approximately three weeks. We make every effort to ship earlier. |
| Optional handles | Pair of hand-machined, polished solid brass handles, nominal 6-inch grips. |
Before connection
Confirm connector pinouts, power requirements and operating limits in the instructions for your unit and build revision. This functional diagram is not a wiring guide.
Ask a compatibility question →
